The Metal Clad Conduit calculator estimates the time to install, the length installed and the weight of Metal Clad Conduit.

• MC Cable Installation Time: Computes the Estimated Install Time for Metal Clad (MC) cable. based on the EMT size, length of conduit and level of difficulty.
• MC Cable Installation Length: Computes the Length of Metal Clad (MC) cable installed based on an installation time period and level of difficulty.
• MC Cable Weight: Compute the weight of Metal Clad Cable based on size and length.
• Rolling Offset: Computes the run and travel distances in a rolling offset

The Math / Science

Metal clad cable is either a smooth or corrugated factory assembled cable containing insulated circuits (wires).   The relationship between the weight of Metal Clad Cable and the length is shown in the attached table based on industry standards.

The relationship between length of conduit, level of difficulty, size of Metal Clad cable and the time to install comes from industry standard numbers.  The relationship between length of cable, size of cable and the weight comes from industry standard numbers.  The following tables are the basis of the weight, length, and time estimates in this calculator.

HOURS PER FOOT MC CABLE INSTALLED
Size	Lvl1	Lvl2	Lvl3	Lvl4
12/2	0.015	0.019	0.023	0.027
10/2	0.018	0.022	0.026	0.031
12/3	0.018	0.022	0.026	0.031
10/3	0.020	0.025	0.030	0.035
12/4	0.020	0.025	0.030	0.035
10/4	0.022	0.028	0.033	0.039

POUNDS PER 1,000 FEET
14/2-Solid	78
14/3-Solid	96
14/4-Solid	114
12/2-Stranded	110
12/2-Solid	105
12/3-Stranded	137
12/3-Solid	131
12/4-Stranded	164
12/4-Solid	157
10/2-Stranded	159
10/2-Solid	152
10/3-Solid	193
10/4-Stranded	243
10/4-Solid	233
8/2-Stranded	234
8/3-Stranded	298
8/4-Stranded	370
6/2-Stranded	332
6/3-Stranded	433
6/4-Stranded	536
4/3-Stranded	635
4/4-Stranded	799
3/3-Stranded	785
3/4-Stranded	987
2/3-Stranded	933
2/4-Stranded	1182

---
